WARNING: Cancer and Reproductive Harm - Fitment Information
- Chevy Impala (2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013)
- Excludes: Police Car and Taxi
Specs and Information
-
Damping Levels: 32-Clicks of Simultaneous Compression & Rebound
-
Height Adjustment: Independent of Spring Preload
-
Front Spring Rate: 8kg/mm (448 lbs/inch)
-
Rear Spring Rate: 5kg/mm (280 lbs/inch)
-
Front Spring Length: 200mm
-
Rear Spring Length: 200mm
-
Front Top Mount: Adjustable Camber Plates
-
Rear Top Mount: Custom Angled Pillowball Mounts
-
Front Spring Inner Diameter: 62mm (2.44 inch)
- Rear Spring Inner Diameter: 62mm (2.44 inch)
- Part Number: R9-HS2-125_3
Product Description
Rev9 Hyper-Street II coilover suspension upgrade features mono-tube shocks with 32 clicks rebound settings and full length adjustable. Mono-tube shocks provides larger capacity for gas and oil to improve comfortable level of typical lowering vehicle. Special 32 clicks of valving allows user to fine tune rebound force settings. Independent spring tension and full length adjustable allows drop without sacrifice comfort by shorten pitch distance.
- Full Steel Alloy Constructions With Aluminum Hardware
- Mono-Tube Shocks Provide Larger Capacity of Oil And Gas
- 32 Clicks of Rebound Force Adjustment
- Full Length Adjustment - Lowers The Car Without Ruining Spring Tension
- Independent Spring Tension - Custom Stiffness Without Change Ride Height
-
User Guide: Rev9 Coilover User Guide
Coilovers are a type of suspension system that allows you to adjust the ride height of your vehicle (only lowers, does not raise). The Rev9 coilovers are designed specifically for the 2006 to 2013 Chevy Impala and are a great option for those looking to lower their car.
Once the coilovers are installed, you can adjust the ride height to your desired level.
It is also recommended that you get an alignment after installing coilovers on your Impala to ensure that your car's suspension is properly adjusted. This will help prevent uneven tire wear and improve your car's handling.
About CoiloverKits.com
We are an authorized and direct dealer for Rev9. We offer full support on these coilovers and we welcome you to contact us with any questions. Rev9 honors and validates their 1 year warranty when purchased through CoiloverKits.com.
